Description
Numerical Control Type NC 400
Through-feed motorized conveyoring belts (No.) 2
Horizontal units/supports (No.) 2
Drilling heads for each horizontal unit (N°) 1
Splindles for each horizontal drilling head (N°) 20
Max. working width (mm) 3200 – Min. working width (mm) 205 (ca.)
Bottom vertical units/supports (No.) 4
Drilling heads/blocks for each bottom vertical unit (N°) 2
Vertical top pressure clamps (N°) 2
Digital quota (axes) display
Total installed power (Kw) 23.7
The CNC controls the movement (X axe) of the mobile horizontal unit
The CNC controls the movement (Y axe) of the stops
